CNC Precision Automatic Lathe
S205A S206A
Feature
?Super rigid gantry type drilling seat
?Variety of end face and lateral live tool combination configurations
?Specializing in stainless steel, large diameter, heavy cutting
?
?
Feature
| Machine tool parameter | S205A | S206A |
| Max. | φ20mm | |
| Main spindle speed | 200～10,000min-1 | |
| Back spindle speed | 200～12,000min-1 | |
| Total number of tools | 35PCS | 39PCS |
| Rapid traverse rate | 32m/min(X1:24m/min) | 32m/min(X1:24m/min,Y2:15m/min) |
| Main spindle motor | 2.2/3.7kW | |
| Width×Depth×Height | 2,110×1,200×1,885mm | |
| Weight | 3,200kg | 3,300kg |
? The above machine parameters are for reference only.
? For special technical specifications, please contact our sales offices or authorized distributors.
? To continuously improve product performance, we reserve the right to modify product designs, specifications, and parameters without prior notice.
