Feature
Thanks to the measures for thermal displacement and automatic compensation system, dispersion from the non-warmup status is reduced.
○Increase the capacity of the coolant tank
○Standard configuration of cutting fluid cooling fan, X and Y axes motor air cooling and tool height displacement compensation
?The main and back spindles are equipped with high-speed spindles of 25,000min-1/20,000min-1 respectively
?Fine precision work is clamped gently by using chucks with adjustable clamping force on both main and back spindles
?Easy-to-use software for turning fine precision work is installed. (Tool-height compensation function)
?High-precision structure with high rigidity bed and symmetrical configuration
?Space saving with the floor space requirement of 0.8㎡
內(nèi)20220629ps.png)
| Machine tool parameter | P013 | P014 | P033 | P034 |
| Max. machinable dia. | φ1mm | φ1mm | φ3mm | φ3mm |
| Maind spindle speed | 25,000min-1 | 25,000min-1 | 20,000min-1 | 20,000min-1 |
| Back spindle speed | — | 25,000min-1 | — | 20,000min-1 |
| Total number of tools | 11pcs | 14pcs | 11pcs | 14pcs |
| Rapid traverse rate | 20m/min | |||
| Main spindle motor | 0.75/1.1kW | |||
| Width×Depth×Height | 1,770×820×1,600mm | |||
| Weight | 1,000kg | 1,050kg | 1,000kg | 1,050kg |
? The above machine parameters are for reference only.
? For special technical specifications, please contact our sales offices or authorized distributors.
? To continuously improve product performance, we reserve the right to modify product designs, specifications, and parameters without prior notice.
