CNC Lathe
M06JC-Ⅱ
Feature
? Compact machine, width 1,165mm× 1,560mm
? Overwhelming cost performance
? On-board conversational programming software, Manual guide 0i is prepared as an option
? Abnormal load detection function decrease the damage in case of machine crush
? Safety setting up by the help of interference prevention function at debug mode
? Accurate machining is realized by the thermal displacement compensation function
Feature
| Machine tool parameter | M06JC-Ⅱ |
| Max. machinable dia. | φ220/φ42(Bar work)mm |
| Main spindle speed | 200～4,500min-1 |
| No. of turret stations | 8-station turret |
| Rapid traverse rate | X,Z:24m/min |
| Main spindle motor | 5.5/7.5kW |
| Width×Depth×Height | 1,165×1,560×1,650mm |
| Weight | 2,380kg |
? The above machine parameters are for reference only.
? For special technical specifications, please contact our sales offices or authorized distributors.
? To continuously improve product performance, we reserve the right to modify product designs, specifications, and parameters without prior notice.
