Feature
?Built-in motor spindle minimizes vibration and improves surface finishes
?Standard-equipped spindle cooling unit reduces thermal displacement
?Adopt hard rail of high rigidity and absorb heavy cutting load to ensure stable machining precision
?Standard-equipment spindle cooling unit reduces thermal displacement
?Machining solutions are sufficient considering workpiece types to adapt to machining requirements of long and round workpiece flexibly
| Machine tool parameter | C300-V |
| Swing over bed | 260mm |
| X/Z axis stroke | 300×300mm |
| Spindle speed | 6,000min-1 |
| Chuck size | 6inch |
| Least input increment | 0.1μm |
| Main spindle motor | 5.5/7.5kW |
| Width×Depth×Height | 1,522×1,535×1,600mm |
| Weight | 1,900kg |
? The above machine parameters are for reference only.
? For special technical specifications, please contact our sales offices or authorized distributors.
? To continuously improve product performance, we reserve the right to modify product designs, specifications, and parameters without prior notice.
