CNC Precision Automatic Lathe
B038M
Feature
? Complete machining of complex-shaped parts from bar stock?
? Complex machining by high-speed tool spindle with the maximum spindle speed of 20,000min-1
??Machine complex parts with tool on main spindle and 40 tools in the tool magazine
? Corresponds to heavy-duty cutting by dual contact holder（CAPTO C4）
Feature
| Machine tool parameter | B038M |
| Max. machinable dia. | φ38mm |
| Main spindle speed | 200～7,000min-1 |
| Back spindle speed | 200～7,000min-1 |
| Total mumber of tools | 52PCS |
| Main spindle motor | 5.5/3.7kW |
| Back spindle motor | 5.5/3.7kW |
| Width×Depth×Height | 2,930×2,000×2,160mm |
| Weight | 7,100kg |
? The above machine parameters are for reference only.
? For special technical specifications, please contact our sales offices or authorized distributors.
? To continuously improve product performance, we reserve the right to modify product designs, specifications, and parameters without prior notice.
