CNC Precision Automatic Lathe
B0385L-III
Feature
? Adjustable collet chuck to ensure short workpiece clamp tightly and stably
??Not required large diameter ground bar stocks
? Shortening remnant, and reducing material cost
Feature
| Machine tool parameter | B0385L-III |
| Max machinable dia. | φ38mm |
| Main spindle speed | 6,000min-1 |
| Back spindle speed | 7,000min-1 |
| Total number of tools | 31PCS |
| Main spindle motor | 7.5/11kW |
| Back spindle motor | 3.7/5.5kW |
| Width×Depth×Height | 2,770×1,515×2,050mm |
| Weight | 4,850kg |
? The above machine parameters are for reference only.
? For special technical specifications, please contact our sales offices or authorized distributors.
? To continuously improve product performance, we reserve the right to modify product designs, specifications, and parameters without prior notice.
